Lantronix SGX 5150 User Manual

9: Administration
SGX 5150 IoT Device Gateway User Guide 117
TM
To Configure Tunnel Serial Settings
Using Web Manager
 To configure the Serial Settings for a specific tunnel, on the Administration page, click
Tunnel > Tunnel 1 > Serial Settings.
Using the CLI
 To enter Tunnel 1 command level: enable > tunnel 1 > serial
Using XML
 Include in your file: <configgroup name=”tunnel serial” instance=”1”>
Packing Mode
With Packing, data from the serial Line is not sent over the network immediately. Instead, data is
queued and sent in segments, when either the timeout or byte threshold is reached. Packing
applies to both Accept and Connect Modes.
Table 9-48 Tunnel Packing Mode Settings
DTR
Select the conditions in which the Data Terminal Ready (DTR) control signal on
the serial line are asserted. Choices are:
 Unasserted
 TruPort = the DTR is asserted whenever either a connect or an accept mode
tunnel connection is active with the Telnet Protocol RFC2217 saying that the
remote DSR is asserted.
 Asserted while connected = the DTR is asserted whenever either a
connect or an accept mode tunnel connection is active.
 Continuously asserted
Tunnel Packing Mode
Settings
Description
Mode
Configure the Tunnel Packing Mode. Choices are:
 Disable = Data not packed.
 Timeout = data sent after timeout occurs.
 Send Character = data sent when the Send Character is read on the Serial
Line.
Threshold
Set the threshold (byte count). If the received serial data reaches this
threshold, then the data will be sent on the network. Valid range is 100 to
1450 bytes. Default is 512.
Note: This configuration option appears when Timeout mode is selected.
Timeout
Set the timeout value, in milliseconds, after the first character is received on
the serial line, before data is sent on the network. Valid range is 1 to 30000
milliseconds. Default is 1000. This setting becomes available when the
Timeout mode is selected.
Note: This configuration option appears when Timeout mode is selected.
Terminal Serial Settings
(continued)
Description

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
