Lantronix SGX 5150 User Manual

SGX 5150 IoT Device Gateway User Guide 142
TM
Table B-6 40 MHz Channels
Table B-7 80 MHz Channels
Notes:
1. Models are only for use in their respective regions. Part numbers ending in U/US for US/
Canada, E/ES for European Union, J/JS for Japan. For other countries, user should confirm
channel compatibility. SGX 5150 has not been certified in all countries.
2. Frequencies from 5150 MHz to 5250 MHz for indoor use only.
3. The unit supports 20 MHz bandwidth channels for 2.4 GHz channels.
4. The unit supports 20, 40, 80 MHz bandwidth channels for 5 GHz channels where appropriate.
5. Region code modifications are not available to the end user.
6. SoftAP mode defaults to channel 1. If the unit is connected as a client to an external AP the
SoftAP channel follows the external AP. The SoftAP channel is not user configurable.
7. In SoftAP mode, the product will not initiate any connection or active scan in 5GHz DFS bands
and will only follow external AP or master device to use a channel.
RoHS, REACH and WEEE Compliance Statement
Please visit http://www.lantronix.com/legal/rohs/ for Lantronix's statement about RoHS, REACH
and WEEE compliance.
Frequency Channel USA/Canada
(U/US part #)
European
Union
E/ES part #)
Japan
(J/JS parts)
5 GHz Band 5190 38 Yes Yes Yes
5230 46 Yes Yes Yes
5270 54 Yes Yes Yes
5310 62 Yes Yes Yes
5510 102 Yes Yes
-
5550 110 Yes Yes -
5590 118 N/A Yes -
5630 126 N/A Yes -
5670 134 Yes Yes -
5755 151 Yes - -
5795 159 Yes
- -
Frequency Channel USA/Canada
(U/US parts)
European
Union
E/ES parts)
Japan
(J/JS parts)
5 GHz Band 5210 42 Yes Yes Yes
5290 58 Yes Yes Yes
5530 106 Yes Yes -
5610 122 -Yes-
5690 138 Yes Yes -
5775 155 Yes
- -

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
