Lantronix SGX 5150 User Manual

6: Network Settings
SGX 5150 IoT Device Gateway User Guide 53
TM
To View or Configure Network Link Settings
Using Web Manager
 To view wireless (wlan0) link statistics, on the Network page, select Wireless Network >
Link.
 To configure wireless (wlan0) link settings, on the Network page, select Wireless Network >
Link > Configuration.
Using the CLI
 To enter the command level: enable > config > if 2 > link
Using XML
 Include in your file: <configgroup name= “interface" instance="wlan0">
Wireless (wlan0) Network QoS
QoS (Quality of Service) can be enabled and configured for both Wired (eth0) Network and
Wireless (wlan0) Network. If enabled, the router will control the flow of outbound traffic according
to the user-defined filters. In other words, QoS improves performance by allowing the user to
prioritize applications. Filters can be defined to prioritize traffic based on the source or destination
network, source or destination port, or the source MAC address. Up to 32 user-defined filters can
be added. The following are predefined priority classes:
 Network Control and Internetwork Control are typically used for network control packets such
as ICMP and have the highest priorities.
 Bandwidth allocation is a minimum 5% each.
 Voice: Bandwidth allocation is minimum 30%.
 Video: Bandwidth allocation is minimum 20%.
 Critical Applications: Bandwidth allocation is minimum 15%.
 Excellent Effort: Bandwidth allocation is minimum 10%.
 Best Effort: Bandwidth allocation is minimum 10%.
 Background: Bandwidth allocation is minimum 5% and has the lowest priority.Table 6-7 shows
the network QoS settings that can be configured including adding new filters.
Table 6-9 Wireless (wlan0) Network QoS Settings
WiFi Direct GO Mode Select to enable or disable. If enabled, WPS issues the credentials when the client
device indicates that it wishes to connect with our device. No password is required.
Go to Wi-Fi Protected Setup (on page 63) to setup WPS.
Wireless Network
(QoS) Settings
Description
State Click to enable or disable state.
Import filters Click to enable or disable import filters to import configurations from other
interfaces.
Uplink Speed Enter the maximum uplink speed. Set 0 to set speed to default.
Field/Button Description

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
