Lantronix SGX 5150 User Manual

9: Administration
SGX 5150 IoT Device Gateway User Guide 90
TM
To Configure Gateway Routing Protocol Settings
Using Web Manager
 To modify gateway protocol settings, on the Administration page, click Gateway >
Configuration > Routing Protocol.
Using the CLI
 To enter the gateway command level: enable > config > gateway > routing
protocols
Using XML
 Include in your file: <configgroup name = "routing protocols">
Virtual IP
The SGX 5150 IoT device gateway allows the configuration of Virtual IP addresses. Virtual IP is a
means to map an externally visible IP address to LAN-side IP addresses. SGX 5150 units will
support creating up to three virtual IP address mappings.
Table 9-18 Virtual IP Settings
Timeout Interval Indicate the number of seconds for the Timeout Interval. Upon expiration of
the Timeout Interval, the routes are no longer valid, however, they are
retained in the routing table for a short time so that neighbors can be notified
that the route has been dropped.
GC Interval Indicate the number of seconds for the GC Interval. Upon expiration of the
GC Interval, the routes are finally removed from the routing table.
OSPF
State Select to Enable or Disable the OSPF state.
Hello Interval Indicate the number of seconds for the Hello Interval. Hello packet will be
sent every Hello Interval seconds.
Dead Interval Indicate the number of seconds for the Dead Interval. Sets the time period
for which hello packets must not have been seen before neighbors declare
the router down.
Virtual IP Settings Description
Enabled (checkbox) Uncheck the Enabled checkbox adjacent to a virtual IP address (if any
listed) to disable it. Keep the checkbox checked to keep the virtual IP
address enabled. A virtual IP address is enabled by default.
Delete (checkbox) Check the Delete checkbox adjacent to a virtual IP address (if any listed) to
be deleted, clicking the Submit button.
Name Enter a name of the virtual IP address.
IP Address Enter the virtual IP address to which the LAN IP address is to be mapped.
LAN IP Address Enter the LAN IP address to which the virtual IP address is to be mapped.
Routing Settings Description

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
