6: Network Settings
SGX 5150 IoT Device Gateway User Guide 66
Configuring WLAN Profile Settings
You can edit, create, or delete a WLAN profile.
Using Web Manager
To edit, create or delete a WLAN profile, on the Network page, click WLAN Profiles.
Using the CLI
To enter the WLAN Profile level: enable > configure > wlan profiles
Using XML
Include in your file:
<configgroup name="wlan profile" instance="profile_name">
Table 6-22 Individual WLAN Profile Settings
Delete (check box) Check the checkbox to the right of the WLAN profile listed right and click the
Submit button which appears, to delete the specific profile.
Name
(link to WLAN profile)
Click an existing WLAN profile listed under the Name column to reveal the
configuration options as shown in Table 6-22 Individual WLAN Profile
Settings. Modify configuration options as desired.
Name
(“Add a new profile” field)
Enter the name of a new profile and click Submit to add it. The profile
appears in the WLAN Profiles list.
WLAN Profile Settings Description
Network Name (SSID) Enter or modify the network name.
State Click to enable or disable.
Suite Select a security suite configuration:
None
Select None to not select a security suite.
WEP
WEP security is available in Infrastructure mode. WEP is a simple and
efficient security mode, encrypting the data using the RC4 algorithm.
However, WEP has become more vulnerable due to advances in hacking
technology. State-of-the-art equipment can find WEP keys in 5 minutes.
For stronger security, use WPA, or the stronger WPA2, with AES (CCMP).
WPA2/WPA Mixed Mode
WLAN Profile Settings Description
