Lantronix SGX 5150 User Manual

9: Administration
SGX 5150 IoT Device Gateway User Guide 96
TM
See Table 9-24 for the line settings that can be modified on the Line 1 - Configuration page. See
Table 9-25 for the line settings that can be established on the Line 1 - Command Mode page.
Table 9-24 Line Configuration Settings
Table 9-25 Line Command Mode Setting
Line Settings Description
Name Enter a name or short description for the line, if desired. By default, there is no name
specified. A name that contains white space must be quoted.
Interface One interface type is available per line:
 RS232 (available for lines 1 and 2)
 USB-CDC-ACM (available for line 3)
State Select to enable or disable the operational state of the Line. The default is Enabled.
Protocol Set the operational protocol for the Line. The default is Tunnel. Choices are:
 None
 Modbus RTU
 Modbus ASCII
 Tunnel
Note: The Line currently only supports None so can be used in Command Mode, for
CLI. Tunnel, as in serial-networking tunneling protocol, will be supported in a future
software release.
Baud Rate Select the desired baud rate from the drop-down menu.
Parity Select parity from the drop-down menu: None, Even or Odd.
Data Bits Select data bits from the drop-down menu: 7 or 8.
Stop Bits Select 1 or 2 stop bits from the drop-down menu.
Flow Control Select None, Hardware or Software flow control from the drop-down menu.
Gap Timer Set the gap timer delay to set the number of milliseconds to pass from the last
character received before the driver forwards the received serial bytes. By default,
the delay is four character periods at the current baud rate (minimum 1 msec). Gap
timer range is 1 to 5000 milliseconds (default value is 4000 msec).
Threshold Set the number of threshold bytes which need to be received in order for the driver to
forward received characters. Default value is 56 bytes.
Line Command Mode
Settings
Description
Mode Set the Command Mode state of the Line. When in Command Mode, a CLI session
operates exclusively on the Line. Choices are:
 Always
 Use Serial String
 Disabled
Note: In order to enable Command Mode on the Line, Tunneling on the Line must
be Disabled (both Connect and Accept modes). Also, custom baud rates are not
supported in Command Mode.
Wait Time Enter the amount of time to wait during boot time for the Serial String. This timer
starts right after the Signon Message has been sent on the Serial Line and applies
only if mode is “Use Serial String”.
Note: This field becomes available when Use Serial String is selected for Mode.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
