Proline Kryomats
YAUE0007 / 2/26/2009 Accessories 105
10 Accessories
Description Application
LAUDA
Catalogue
number:
LAUDA Wintherm Plus
PC Program
Control of the thermostat, online display of all
values as a graph with free choice of time
frame. Incl. RS 232 cable (2m)
LDSM2002
RS232/ 485 Interface modules Digital Communication, operation of the
LAUDA PC software Wintherm Plus Ö 8.3
LRZ 913
RS 232 Cable (2m) Thermostat-PC Sub-D (9 pin. 9 pin) EKS 037
RS 232 Cable (5m) Thermostat-PC Sub-D (9 pin. 9 pin) EKS 057
Analogue module Current and voltage interface Ö 8.4 LRZ 912
Relays module with 3 input and 3 output
channels
Import and export of thermostat signals
Ö 8.5.1
LRZ 915
Relays module with 1 input and 1 output
channel
NAMUR NE28 functionality Ö 8.5.2
LRZ 914
T-piece adapter cable for the LAUDA
internal bus (LiBus) c.
For the connection of further LiBus
components (with heating thermostats two
LiBus c connections are not occupied and
one with cooling thermostats)
EKS 073
Extension for LiBus c 5m EKS 068
Extension for LiBus c 25m
For LiBus c components, but especially for
remote operation with the command console.
EKS 069
Automatic refill device with LiBus c
control.
Evaporating heat transfer liquid is
automatically topped up.
LCZ 9661
Shut-off unit with LiBus c control. Prevents the return of cooling liquid into the
bath from external containers located above
the bath.
LCZ 9673
Level controller without reverse-flow
protection, mechanical function.
Keeps the liquid level in an open external
bath at a constant level.
LCZ 0660
Raising platforms, application frames
etc.
We will inform you about other accessories on
request Ö 9.3.7. Also, refer to our special and
accessory broachers.
c LiBus = LAUDA internal BUS (based on CAN).
