View of the socket (front) or solder side of plug:
Pin 1 Output 1
Pin 2 Output 2
Pin 3 0 V reference potential
Pin 4 Input 1
Pin 5 +24 V (max. 0.1 A)
Pin 6 Input 2
)
Use shielded lines. Connect shielding with connector housing!
8.5 Contact module
8.5.1 Contact module LRZ 915 with three inputs and three outputs
Contact module Cat. no. LRZ 915) on 15 pole SUB-D socket. With three relay contact outputs
(changeover, max. 30V/ 0.2A) and three binary inputs for control via external voltage-free contacts.
The following functions are made available by the inputs:
- Set fault with function: Master: E @K@ or Command: Fault .
- Set Stand by with function: E Rra or Stand by .
- Control programmer (Input 1 activates programmer 1, input 2 activates programmer 2 etc. At the
first “close” the programmer gets starting, “open” removes it in “pause”. The next “close” initiate
“continue”) with function: E Op5 or Programmer .
- Control alternating mode (the switching state contact “open“ or “closed” allot to two different
setpoint temperatures): E r1B or alternating mode .
- Controller mode (the switching state input “open” or “closed” can allotted to two different control
temperature sources. E. g. internal ↔ external control): E Bml or type of control .
The following functions are made available by the outputs:
- Signal various fault states: E ch@ or fault diagnosis .
- Signaling standby: E Rra or Standby .
- Providing status of the window discriminators (inside ↔ outside): E VWh or temperature
range .
- Providing the programmer status: E Op5 or Programmer .
- Signaling refill of heat transfer liquid: E E0K or Refill .
1
5V
Input
Output
1 2 3
Contact module LRZ 915; SUB-D
12 4 5 6 13 14 15 7 8
2
5V
3
5V
1 9 2 10 3 11
