Proline Kryomats
58 Starting up YAUE0007 / 2/26/2009
7.7 Graphical display of temperature measurements (Command)
Command
Screen and Graph
Press the soft key Screen a number of
times as required until the graph recorder
window appears.
With the soft key Graph you enter the
menu for the configuration of the graph
recorder.
Mode defines,
whether the recording is to run
continuously as Online graph ,
or whether it is to be started with Start
record and later terminated with Stop
record . When this start/stop mode is
active, Rec flashes at the top left of the
display.
Displayed value defines,
which of the measurements T
int
, T
set
and/or T
ext
is to be graphically displayed.
In the menu all combinations are offered.
Legend defines,
whether the axis label is to be invisible or
visible .
Sample time defines with which time
interval the measurements are recorded. 5
possibilities are offered:
From 2s (max. 1h45min) up to
2min (max. 105h) .
Time axis defines over which time range
the measurements are to be displayed.
With Automatic the program finds the
optimum display.
Manual input from 9min up to 144h .
Time base defines whether scaling is to
be carried out.
With Relative the start occurs at
00:00:00.
With Absolute the current time is
displayed.
Hel
p
Menu End T
set
T
fix
Mode
Displayed value
Legend
Sample Time
Time axis
Time base
Temp. scale
Temp. limits
Online graph
Start Record
Hel
p
Menu Screen T
set
Gra
h
T
set
25.00 T
int
25.01 T
ext
25.02
T °C
27.00
26.00
25.00
24.00
23.00
11:22:00 11:25:00 11:28:00 11:31:00
Rec
Hel
p
Menu End T
set
T
fix
Mode
Displayed value
Legend
Sample time
Time axis
Time base
Temp. scale
Temp. limits
Tset Tint Text
Tset Tint
Tset Text
Tint Text
Tint
Text
Tset
