Page #95 background imageLoading...
Page #95 background image
Proline Kryomats
YAUE0007 / 2/26/2009 Maintenance 95
9 Maintenance
9.1 Device status
The thermostat can be conveniently checked with the Command Console.
9.1.1 Interrogating the device type
Æ Settings Æ Device status Æ Device type
9.1.2 Software version
Æ Settings Æ Device status Æ Software version .
The versions of the control system ( Control ), safety system ( Safety ), Command Console
( Command ), cooling system ( Cool ) and, where applicable, other connected modules are displayed.
9.1.3 Serial numbers
Æ Settings Æ Device status Æ Serial numbers .
The serial number of the Master ( Master ), Command Console ( Command ), cooling system ( Cool )
and other connected modules are displayed.
9.1.4 Device data
Command
Device data
Æ Settings Æ Device status Æ
Device data Æ Display
T ext shows various actual temperatures
in °C from ext. Pt100 and the modules.
T cont. head and T heatsink are
temperatures of electronics in the Master
in °C.
Pump power in Watts, speed in rpm,
current in ampere (A).
T
int
indicates the current internal bath
temperature in °C.
Mains voltage in percentage (%) of
nominal and frequency in hertz (Hz).
Level indicates the liquid level in the
internal bath.
Voltage of power transformer, 5V supply
and fan voltage in Volt.
Cur. cons.: Mains current consumption in
Ampere.
T ext Pt 25.70 Tint -8
T ext analog ---.-- Mains U(%) 100.74
T ext serial ---.-- Mains frequ. 50
T cont. head 39.80 Level 4
T heatsink 51.68 Low voltage 27.90
Pump pow. 44.90 5V supply 5.00
Pump rpm 5460 Fan voltage 7.0
Pumpe cur. 1.68 Cur. cons. 2.84
Hel
p
Menu End T
set
T
fix
