Doc No. FM0410 issue N Page 7
inc battery standby & Digital Communicator
Advent xt Ethernet InterfaceMK3)
stores Telecare data for remote analysis
typically 80 PA intercoms per PA amplifier
maximum 255 intercoms/callpoints per system
Combined Intercom + PA/Extracare
Combined Intercom + PA & BLE
Lift Callpoint (Flush S/S)
Lift Callpoint (Surface ABS)
maximum 5 per intercom (with LED)
use mains powered detectors with integral standby
battery & normally open relay output
use 12V DC PIR’s with normally closed relay output
(additional PSU may be required)
Miniature Thermal Printer
Total 16 per system (maximum 12 zoned)
169MHz Zoned Network Receiver
1 per ZXT325 Network Receiver
maximum 2 per ZXT290 combined intercom
slave telephone for above
1 per Door Panel (for lock supply)
WIRING REQUIREMENTS
On new installations the system wiring network should be a 6 pair CW1308 BT spec cable, on sites with existing cabling a
minimum of 5 twisted pairs are required (or 4 pairs without PA or door entry).
The telephone wiring network should be a 2 pair CW1308 BT spec cable with BT master sockets. A dedicated PSTN line is
required if the facility to report calls to a remote Control Centre is specified.
See separate manuals for the different IP-DECT and VoWiFi and telephone solutions and wiring requirements.
SYSTEM PROGRAMMING
A Laptop PC with Windows 98, 2000 or XP lnternet Explorer and a serial data cable is required for all system programming.
Windows 7 Laptops can be used with a MicroSoft application that runs XP mode (only compatible with Windows 7
Professional, Enterprise or Ultimate editions). See the Advent xt Programming Manual (Tynetec Doc No. FM0411).
