Doc No. FM0410 issue N Page 58
44. SPECIFICATION - DOOR ENTRY PANEL
ZXT411 Standard, ZXT422 with Emergency Button (AHA Only)
24V DC @ 30mA standby (250mA active)
Handsfree Voice Switched (simplex with combined intercoms)
1 to 4 = Set Binary ID, 5/6/7/8 all ON
LK1 = Fail Secure or Fail Safe Lock Type, LK2 = Expander Fitted,
LK3 = Expander Type, LK4 = Mute Speech Messages and Tones
VR2: Audio to phone, VR3: Audio to door, VR4: VOX sensitivity
VR5: Audio to warden, VR6: Warden audio to door & speech messages
Optional HM1140 Surface Cowling required
Optional HM1105 Flush Cowling required
20mm Diameter Stainless Steel
Protected by Fine Mesh Stainless Steel Grill
Protected by Fine Mesh Stainless Steel Grill
High Visibility Yellow Halo around Pushbuttons, Pip on No. 5
Yes (can be disabled with LK4 in position B)
2 Line x 16 Character Backlit LCD (8mm High Characters)
5mm Clear Makralon Polycarbonate
Panel Mount Reader Option
Yes - standard 40mm square cut-out with 4 studs on 48.5mm centres
Relay Contacts rated 30V DC @ 1A
LK1A = Fail Secure, LK1B = Fail Safe
Adjustable 1 to 255 Seconds (default 10 Secs)
Adjustable 1 to 99 (default 8 Cycles)
Adjustable 1 to 255 Seconds (default 60 Secs)
4 Programmable 4 Digit Access Codes
3 Programmable Trade Time Periods Per Day
Normally Closed Door Contact required
Normally Open Press to Exit Button required
6 No. M5 x 12mm Countersunk Allen Head Bolts
406mm x 160mm x 2.64mm (HxWxD)
16 SWG Galvanized Mild Steel
406mm x 160mm x 60mm (HxWxD)
Ingress Protection Rating
