Doc No. FM0410 issue N Page 60

46. SPECIFICATION - LINE SELECTOR

Tynetec Part No.

ZXT330

EMC Approval

N/A

Safety Approval

N/A

Features

Power Requirement

12V DC @ 40mA active (0mA standby)

BT47 Relay

Fully sealed DPDT contacts rated 2A @ 30V DC

Telecom Connectors

3 x BT Type 431A Sockets

Screw Terminals

12V & 0V Enable

Telecom Leads (2 No.)

1 metre long 6 core FCC68 flat cable with BT Type 431A Plugs

Mechanical

Enclosure Material

Light Grey ABS (RAL 7035)

Flammability Rating

UL 94 V-0

Ingress Protection Rating

IP54

Dimensions

170mm x 85mm x 34mm (LxWxD)

Weight

178 grams

Environmental

Operating Temperature

C to +40

Operating Humidity

10% to 90% RH

Relative Humidity

Non-condensing

47. SPECIFICATION - DATA REPEATER

Tynetec Part No.

ZXT340

EMC Approval

N/A

Safety Approval

N/A

Features

Power Requirement

24V DC @ 10mA (standby)

4 Jumpers

Pull-up/pull-down resistors on RS485 IN/OUT terminals

4 DIL Switch SW1

Switchable end of line resistors on RS485 IN terminals

4 DIL Switch SW2

Switchable end of line resistors on RS485 OUT terminals

RS485 IN LED Indicators

LED1: Yellow RX, LED2: Red TX

RS485 OUT LED Indicators

LED3: Yellow RX, LED4: Red TX
