LEGRAND tynetec Advent XT User Manual

Doc No. FM0410 issue N Page 51
37. SPECIFICATION - INTERCOM
Tynetec Part No’s
ZXT201/206/211/216/221/226/280/282/284/286/290
EMC Approval
EN 55022
Safety Approval
EN 60950
Max No. Intercoms
255
Data Connection
RS485 (19200 Baud)
Power Requirement
24V DC @ 2mA (standby)
Audio Channel
Handsfree Voice Switched
8 Way Address DIL Switch
Set Binary ID
8 Way Options DIL Switch
Enable Auxiliary Devices
3 Jumpers
LK1/LK2/LK3 fit to select different Master/Slave combinations
Loudspeaker
35 Ohm 0.5 Watts
Features
Wipe-clean Tactile Keypad
Standard 5 Buttons (7 Buttons on Combined Door Entry range)
Emergency Pull Cord
1.7 metres long Orange Polypropylene with 2 Orange Triangular Grips
Emergency Call Button
Red Halo with red LED illuminated symbol
I’m OK Button
Green with white symbol & green LED indicator
Privacy Button
Amber with white symbol & amber LED indicator
Message Waiting Button
Blue with white symbol & blue LED indicator
Test Mode Button
Grey with white symbol & white LED indicator
Talk Button
ZFT28x/290 only: Amber with white symbol & amber LED indicator
Door Open Button
ZFT28x/290 only: Green with white symbol & green LED indicator
All Call Speech
PA models only - optional ZXT155 PA Amplifier required
All Call Fire Tone
PA models only - optional ZXT155 PA Amplifier required
Extracare Cancellation Mode
Extracare models only (Magnetic Fob required – Part No. YW9970)
Activity Monitoring
Yes - optional PIR detector required
Away Mode
Yes - optional PIR detector required
Intruder Mode
Yes - optional PIR detector required
Visual Call Indication
Yes - optional ZSL045 Master Blue Strobe required
Audible Reassurance
Yes - integral Piezo Beeper 4kHz 75dB @ 1m
Smoke Alarm Input
Yes - N/O
Pullcord Input
Yes - selectable for N/O or N/C
Pullcord Monitoring
Yes - 4K7 EoL resistor required on N/O type (not required on N/C)
Pullcord LED Reassurance
Yes - max 5 Pullcords with LED reassurance
PIR Input
Yes - N/C
Additional Inputs
Yes - 4 x N/O (default: client wandering/low temp/CO/Gas)
Relay Output
Yes - 1 x N/O (contacts rated 30V DC @ 1A)
Bluetooth Option
Yes - ZXT290 model only
Mechanical
Enclosure Material
White Polycarbonate base & lid, Silver ABS trim
Flammability Rating
UL 94 V-0 (GWFI 850
o
C)
Ingress Protection Rating
IP20
Dimensions
174mm x 112mm x 49mm (HxWxD)
Weight
388 grams (PA model)
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
