LEGRAND tynetec Advent XT User Manual

Doc No. FM0410 issue N Page 61
48. SPECIFICATION - DOOR OPEN ALARM
Tynetec Part No.
ZDA025
EMC Approval
N/A
Safety Approval
N/A
Features
Power Requirement
24V DC @ 50mA (standby)
Jumpers LK1&LK2
Cut LK1 and fit LK2 for 12V DC supply
Jumper LK3
Cut to isolate Piezo sounder
Potentiometer VR1
Adjust delay before alarm 1 second to 5 minutes
Piezo Sounder
4kHz 80dB @ 10cm
Relay Output
Changeover contacts rated 30V DC @ 1A
Door Contact
Normally Closed Type (not supplied)
Keyswitch
2 position/key removeable in both positions, Key No. 900
Mechanical
Lid Material
White ABS
Backbox
RRP M2DP2 2 Gang Surface Pattress Box
Flammability Rating
UL 94 V-0
Ingress Protection Rating
IP40
Dimensions
146mm x 86mm x 40mm (HxWxD)
Weight
221 grams
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
