LEGRAND tynetec Advent XT User Manual

Doc No. FM0410 issue N Page 57
43. SPECIFICATION - MANAGER’S DISPLAY PANEL
Manager’s Display Panel
Tynetec Part No.
ZXT315
EMC Approval
EN 55022
Safety Approval
EN 60950
Display
Size
10.4”
Type
VGA TFT Colour
Resolution
640 x 480 pixels
Backlight
LED
Touch Type
Resistive
Memory
1GB Industrial SLC SD Card
Operating System
Windows CE 6.0
Power
12V DC (3.5m Lead)
Data
Half Duplex RS485 (3.0m Lead)
Power Supply
Manufacturer/Model
Elmdene G13802N-A (Tynetec Part No. W00525)
EMC Approval
2014/30/EU
LVD Approval
2014/35/EU
Environmental Approval
RoHS2: 2011/65/EC, WEEE: 2012/19/EU
Type
Switch Mode PSU with Electronic Overload Protection
Input Voltage
100V to 240V AC 50/60Hz
Output Voltage/Current
13.8V DC @ 2A
Output Ripple
150mV peak to peak
LED Indicators
Green = Mains Present and Red = Fault (Output/Battery Fuse Fail)
Mains Fuse Protection
T2.0A 20mm HRC
Load Fuse Protection
F2.0A 20mm Glass
Battery Protection
Re-settable PTC
Enclosure Material
White powder coated 18 SWG steel with hinged lid
Ingress Protection Rating
IP41 (indoor sheltered)
Dimensions
200mm x 230mm x 80mm (HxWxD)
Weight
1.85 kg (excluding battery)
Operating Temperature Range
-10
o
C to 40
o
C
Operating Humidity
75% RH, Non-condensing
Standby Battery
Manufacturer/Model
Yuasa NP3.4-12 (Tynetec Part No. F00040)
Type
12V 3.4Ah Rechargeable Lead Acid
Dimensions
133mm x 66mm x 60mm (LxWxH)
Weight
1.00 kg
Operating Temperature Range
-15
o
C to 50
o
C
Display Mechanical
Enclosure
Black ABS
Mounting
VESA (100mm x 100mm wall fixing centres)
Dimensions
226mm x 296mm x 59mm (HxWxD)
Weight
1.85 kg (excluding PSU)
Display Environmental
Operating Temperature
5
o
C to 40
o
C
Operating Humidity
0% to 90% RH
Relative Humidity
Non-condensing
