LEGRAND tynetec Advent XT User Manual

Doc No. FM0410 issue N Page 49
35. SPECIFICATION - CONTROLLER
Tynetec Part No.
ZXT101
EMC Approval
EN 55022
Safety Approval
EN 60950
Social Alarm Standard
EN 50134
System
Removable Memory
Tynetec Dataflash Card (Part No. A00480)
Real Time Clock
Auto-DST adjustment
LED Indicators
Power/Data/Line Seize
Protocols
BS8521/BS7369/TTNew/TT92 (+NOW IP with Digital Communicator)
I/O
Inputs
4 x N/O inputs (switched 0V)
Outputs
4 x N/O relay outputs (125VAC/60VDC/1A rated)
RS232 Ports
2
RS485 Ports
1
Ethernet Port
1 x 10/100 BASE-TX (with Digital Communicator)
DECT Port
1
PSTN Port
1
Features
No. of Network Nodes
255 (includes intercoms, lift/ext call points, door panels & NTR’s)
No. of Managers Panels
1
No. of Door Panels
16
No. of Network Receivers
16
No. of Speech Channels
1
Audio Control
Warden Call: HVS (Hands Free Voice-switching)
Door Entry: simplex combined intercoms, half duplex telephones.
No. of Local Offsite Tel. No’s
6
No. of Remote Offsite Tel. No’s
3
Power Supply
Manufacturer/Model No.
Ecopac RSP-150-27 (Tynetec P/No. W00581)
Input
85-264VAC 47/63Hz
Output
27V DC @ 5.6A (150W)
Efficiency
89.5%
Protection
Overload/Over Voltage/Over Temperature (auto shutdown/recovery)
Mains Lead
1.5m x 2183Y white 0.5mm 3 core cable with IEC 90
o
Free Socket
Rechargeable Battery Type
2 x 12V 5Ah Sealed Lead Acid (Tynetec P/No. F00050)
Battery Standby Time
8 Hours (based on 5 calls/hour on a typical 40 way system)
Mechanical
Enclosure
Polyester Powder Coated 18 SWG Mild Steel (RAL7035)
Mounting
Wall Mount
Ingress Protection Rating
IP40
Dimensions
400mm x 500mm x 80mm (HxWxD)
Weight
11.60 kg
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
20% to 90% RH
Relative Humidity
Non-condensing
