LEGRAND tynetec Advent XT - Specification - Master Strobe; Specification - Slave Strobe

Doc No. FM0410 issue N Page 62
49. SPECIFICATION - MASTER STROBE
Tynetec Part No.
ZSL045
EMC Approval
N/A
Safety Approval
N/A
Features
Power Requirement
10V DC @ 2mA (standby) 90mA active
Data Connection
SDATA & SCLK
Max No. Strobes
1 per intercom
Strobe Lens Colour
Blue
Strobe Lamp
Xenon
Strobe Flash Rate
100 per minute
Strobe Power Output
1 Watt
Strobe Flash Duration
20 Seconds
Mechanical
Enclosure Material
Off White ABS (RAL 9002)
Flammability Rating
UL 94 HB
Ingress Protection Rating
IP40
Dimensions
110mm diameter x 57mm deep
Weight
135 grams
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
50. SPECIFICATION - SLAVE STROBE
Tynetec Part No.
ZSL046
EMC Approval
N/A
Safety Approval
N/A
Features
Power Requirement
12V DC @ 0mA (standby) 90mA active
Max No. Strobes
1 per combined intercom
Strobe Lens Colour
Blue
Strobe Lamp
Xenon
Strobe Flash Rate
100 per minute
Strobe Power Output
1 Watt
Strobe Flash Duration
20 Seconds
Mechanical
Enclosure Material
Off White ABS (RAL 9002)
Flammability Rating
UL 94 HB
Ingress Protection Rating
IP40
Dimensions
110mm diameter x 57mm deep
Weight
115 grams
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
