Service Manual JET3
114 Rev. 1.0
2. Select softkey <ServiceFunctions> (1) and go in the menu <Hydraulic> (2).
Select tab <Printhead> (3) and push the buttons <Ink off> (4) and <Jet adjust> (5).
1 – Softkey <Hydraulik settings>
2 – Menu <Hydraulik>
3 – Menu <Printhead>
4 – Button <Ink off>
5 – Button <Jet Adjust>
3. Remove head cover. Loose the retaining screws with a 2mm allen key around one
turn and remove the inner head cover.
4. Dismantle the nozzle therefore take a look at the chapter
<removing and cleaning the nozzle>.
1
2
3
4
5
