Service Manual JET3
Rev. 1.0 139
5. Remove the electrode block
Remove the 6 torx screws with a torx screwdriver (T8) and unplug the electrode block
from the print head.
6. Disconnect the electrode block from the print head electronic parts.
Unplug the charge board!
Remove the fixing screws from the
HV-Cable with an Allen key (SW 1,5)!
