Service Manual JET3
Rev. 1.0 77
Attention:
Never use a balled head allen key, otherwise you are damaging the screws!!!
5. Open the allen screw (1,5 metric) from the drop production unit, until it is possible to
bring it into the service-position. Then close the screw until the unit is locked.
6. Touch the <Jet Adjust> button (1). Now the gutter tube is moving automatically to a
pre defined service-position (4200) (2).
1 – Button < Jet Adjust >
2 – Displayfield <Service position
1
2
