Service Manual JET3
94 Rev. 1.0
3. Remove print head cover. Release fixing bolts with allen key (SW 2,0 mm) by turning
about one rotation and remove the interior cover.
Attention:
It is not allowed to use a golf ball head allen keys,otherwise screw heads
could be damaged.
4. Remove the mounting plate (with drop production unit).
Remove the 5 retaining screws + the washers with an allen key (SW 2,0 mm)
