316
Leica mojo3D, mojo3D Enhancements
Power:
• The power supply for the multi section control kit must be able to supply 8 A
continuously from a permanent 12 V supply.
• If the Electric Steer Kit is also being used, the power supply must be able to
supply 13 A continuously at 12 V, and the multi section control kit must be
connected closest to the power source.
• A 5 m (16.4 ft) cable is supplied so that direct connection to the battery is
possible if required.
The Leica AS400 section controller should be located in any convenient place in the
vehicle cabin.
Software configu-
ration, step-by-
step
1. On the main navigation screen, tap the settings button.
2. On the flyout menu, tap the Vehicle Setup button.
3. Tap until the Section Controller / Implement mode screen is displayed.
4. Tap Leica AS400, to select it as the section controller.
