Lenovo ThinkServer TD340 Operating System Installation Guide

Note:IfthemessagePressanykeytobootfromcdisdisplayed,pressanykey.IfthemessageWindows
Setup[EMSEnabled]isdisplayed,pressEnter.
2.IntheInstallingWindowswindow,selectthelanguageandotheroptions.Then,clickNext.
3.ClickInstallnow.
4.Selecttheoperatingsystemthatyouwanttoinstall,andthenclickNext.
5.ReadthelicensetermsandselectIacceptthelicenseterms.Then,clickNext.
6.Selectthetypeofinstallationyouneed.ThefollowingstepsarebasedonthescenariothatCustom
(Advanced)isselectedinthisstep.
7.Whenthe“WheredoyouwanttoinstallWindows?”windowisdisplayed,connecttheUSBstorage
devicethatcontainsthedrivertoyourserverandclickLoadDriver.
8.GotothefolderwherethedriverisstoredandclickOK.
9.SelectthedriverthatyouwanttoinstallandclickNexttoinstallthedriver.
10.Inthe“WheredoyouwanttoinstallWindows?”window,clickDriveoptions(advanced).
11.Selecttheharddiskdriveonwhichyouwanttoinstalltheoperatingsystem,andthenclickNew.
12.Typetheamountofspace(inMB),andthenclickApply.
13.IntheInstallWindowswindow,clickOK.
14.Ensurethatthedrivepartitioniscorrect,andthenclickNext.Theinstallationbegins.
Note:Y ourserverwillrestartseveraltimesduringtheinstallation.
15.Changeyourpasswordwhenprompted.
Note:Thepasswordmustbeacombinationofuppercaseletters,lowercaseletters,andnumbers.
16.Followtheinstructionsonthescreentologintotheoperatingsystemwhenprompted.
InstallingdriversfortheWindowsSmallBusinessServer2011Premium
Add-onoperatingsystem
ToinstalldriversfortheWindowsSmallBusinessServer2011PremiumAdd-onoperatingsystem,referto
therelatedtopics.
•“Installingthedriverforthechipset”onpage5
•“InstallingthedriverforanEthernetcard”onpage5
•“Installingthedriverforanonboardgraphicscard”onpage5
•“InstallingthedriverforanHBAcard”onpage6
•“InstallingthedriverforIntelManagementEngineInterface”onpage7
•“InstallingthedriverforaCNAcard”onpage7
InstallingtheMicrosoftWindowsServer2012operatingsystemand
drivers
Thistopicprovidesinstructionsonhowtoinstallthefollowingoperatingsystemsandthedrivers:
•MicrosoftWindowsServer2012DatacenterEdition
•MicrosoftWindowsServer2012StandardEdition
InstallingtheMicrosoftWindowsServer2012operatingsystem
ToinstalltheMicrosoftWindowsServer2012operatingsystem,dothefollowing:
12ThinkServerTD340OperatingSystemInstallationGuide

Lenovo ThinkServer TD340 Specifications

General

Tcase	80 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR19T
Processor cache	20 MB
Processor cores	8
Processor model	E5-2440v2
System bus rate	7.2 GT/s
Processor series	Intel Xeon E5-2400 v2
Processor socket	LGA 1356 (Socket B2)
Processor threads	16
Processor codename	Ivy Bridge EN
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor boost frequency	2.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	95 W
Number of processors installed	1
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066, 1333, 1600 MHz
Memory bandwidth supported by processor (max)	38.4 GB/s
Maximum internal memory supported by processor	384 GB
HDD size	3.5 \
RAID levels	0, 1, 10
HDD interface	-
Optical drive type	DVD±RW
Total storage capacity	0 GB
Maximum storage capacity	32 TB
Number of HDDs installed	0
Supported storage drive interfaces	SAS, Serial ATA
Memory slots	12
Internal memory	8 GB
Memory clock speed	1600 MHz
Maximum internal memory	192 GB
Memory layout (slots x size)	1 x 8 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	10 Gigabit
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Compatible operating systems	- Microsoft Windows Server 2012 R2\\r - Microsoft Windows Server 2012\\r - Microsoft Windows Server 2008 R2\\r - Microsoft Windows Server 2008\\r - Microsoft Windows Small Business Server 2011\\r - Novel SUSE Linux Enterprise Server\\r - Red Hat Enterprise Linux Server\\r - VMware ESXi\\r - Citrix XenServer
Chassis type	Tower (5U)
Power supply	800 W
Sustainability certificates	ENERGY STAR
Processor ARK ID	75263
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	594.87 mm
Width	194.82 mm
Height	429.77 mm
Weight	28000 g
