8.Removethefourscrews1attherearofthechassisandthetwoscrews2onthemetalclipatthe
frontofthepowerdistributionboardandcageassembly.Then,pushthepowerdistributionboardand
cageassemblyfromtherearuntilitisreleasedfromthemetalretainingtab3andthencarefullylift
itoutofthechassis.
Figure90.Removingthepowerdistributionboardandcageassembly
9.Touchthestatic-protectivepackagethatcontainsthenewpowerdistributionboardandcageassembly
toanyunpaintedsurfaceontheoutsideoftheserver.Then,removethenewpowerdistributionboard
andcageassemblyfromthepackage.
Chapter6.Installing,removing,orreplacinghardware153
