CAUTION:

Theheatsinkandfanassemblyandthemicroprocessormightbeveryhot.Turnofftheserverand

waitthreetoveminutestolettheservercoolbeforeremovingtheservercover.

Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother

computerforreference.

Toreplacethemicroprocessor,dothefollowing:

1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall

powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.

2.Removetheservercover.See“Removingtheservercover”onpage87.

3.Laytheserveronitssideforeasieroperation.

4.Removetheheatsinkandfanassembly.See“Replacingtheheatsinkandfanassembly”onpage162.

5.Gentlypressdownthesmallhandleonthemicroprocessorsocketandthenpullthehandlealittlebit

outwardtoreleaseitfromthesecuredposition.Then,pivotthehandleupwarduntilthehandleandthe

microprocessorretainerareinthefullyopenposition.

Note:Yourmicroprocessorandsocketmightlookdifferentfromtheoneillustrated.

Figure100.Liftingthehandletoopenthemicroprocessorretainer

166ThinkServerTS430UserGuide
