Thefollowingillustrationshowsthelocationsofthehot-swapharddiskdrivebackplanes.Youneedtoopen

theservercoverandremovethefrontsystemfanstoaccessthebackplanes.See“Removingtheserver

cover”onpage87and“Replacingthefrontsystemfan”onpage157.

Notes:

1.Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.

2.Thefollowingillustrationisbasedonservermodelsthathavevetoeight3.5-inchhot-swapSATAor

SASharddiskdriveswithtwobackplanes1.

Figure19.Hot-swapharddiskdrivebackplanelocations

Backplanefor3.5-inchhot-swapharddiskdrives

Thistopicprovidesinformationtohelpyoulocatetheconnectorsona3.5-inchhot-swapharddiskdrive

backplane.

36ThinkServerTS430UserGuide
