Thefollowingillustrationsshowtheconnectorsona3.5-inchhot-swapharddiskdrivebackplane.

Figure20.Frontviewofthe3.5-inchhot-swapharddiskdrivebackplane

1Slot0fora3.5-inchSATAorSAShot-swaphard

diskdrive

3Slot2fora3.5-inchSATAorSAShot-swapharddiskdrive

2Slot1fora3.5-inchSATAorSAShot-swaphard

diskdrive

4Slot3fora3.5-inchSATAorSAShot-swapharddiskdrive

Figure21.Rearviewofthe3.5-inchhot-swapharddiskdrivebackplane

18-pinpowerconnector

•Forthe3.5-inchhot-swapharddiskdrivebackplaneonthelowerharddiskdrivecage,connecttheP5

powerconnectorofthepowersupplytothe8-pinpowerconnectoronthebackplane.

•Forthe3.5-inchhot-swapharddiskdrivebackplaneontheupperharddiskdrivecage,connecttheP4

powerconnectorofthepowersupplytothe8-pinpowerconnectoronthebackplane.

2Mini-SASsignalcableconnector

Usedtoconnectthemini-SASconnectorononeendofthemini-SASsignalcable.

Chapter3.Productoverview37
