Table 21. Parts list
Index
Description
Tier 1 CRU Tier 2 CRU FRU
Consumable
and
Structural
parts
For more information about ordering the parts shown in Figure 13 “Server components” on page 50:
https://datacentersupport.lenovo.com/products/servers/thinksystem/sr630v2/7z70/parts
1
Top cover
√
2
Standard air baffle
√
3
Riser assembly (LP)
√
4
Riser assembly (LP+LP)
√
5
Riser assembly (LP+FH)
√
6
Rearwall bracket
√
7
PCIe adapter
√
8
System board
√
9
RAID super capacitor holder (on
chassis)
√
10
RAID super capacitor holder (in riser
cage)
√
11
RAID super capacitor
√
12
OCP 3.0 Ethernet adapter
√
13
Power supply unit
√
14
Power supply unit filler
√
15
Front I/O assembly with diagnostics
panel (right)
√
16
Front I/O assembly
√
17
External LCD diagnostics handset
√
18
LCD diagnostics panel assembly
√
19
EIA (right)
√
20
LCD diagnostics panel
√
21
Front I/O assembly with diagnostics
panel (top)
√
22
2.5-in drive bay filler
√
23
2.5-inch drive
√
24
3.5-inch drive
√
25
7mm drive cage
√
26
7mm drive backplane (bottom)
√
27
7mm drive backplane (top)
√
Chapter 2. Server components 51
