Table 39. Recommended installation priority for different types of PCIe adapters
1. OCP Ethernet adapter 6. InfiniBand adapter
2. Custom form factor (CFF) internal HBA/RAID adapter
7. Fiber channel adapter
3. Standard form factor (SFF) RAID adapter/Re-timer
adapter
8. Network adapter
4. SFF HBA 9. NVMe PCIe flash adapter
5. GPU adapter 10. External HBA/RAID adapter
When installing a specific PCIe adapter, refer to the following suggested slot installation priority:
Table 40. Recommended slot installation priority for PCIe adapters
Recommended slot
installation priority
PCIe adapters
Must be installed in slot 1
• SFF HBA/RAID adapter
• ThinkSystem x16 Gen 4.0 Re-timer adapter (for 4x NVMe)
Must be installed in slot 2
(configured as a full-height
slot)
• ThinkSystem NVIDIA Quadro P2200 5GB PCIe Active GPU
• ThinkSystem Broadcom 57454 10/25GbE SFP28 4-port PCIe Ethernet Adapter
Must be installed in slot 3
ThinkSystem Mellanox HDR/200GbE 2x PCIe Aux Kit
Note: ThinkSystem Mellanox HDR/200GbE 2x PCIe Aux Kit must be used together
with Mellanox ConnectX-6 HDR IB/200GbE Single Port x16 PCIe Adapter and
functions as the auxiliary adapter. Two CPUs are required if both adapters are used,
with the primary adapter installed in slot 1 or slot 2 while the auxiliary adapter installed
in slot 3.
Slot 1 > Slot 3 > Slot 2
• ThinkSystem NVIDIA Tesla T4 16GB PCIe Passive GPU
• NVIDIA Tesla T4 16GB Base Card (for China only)
• NVIDIA Quadro P620 GPU
• Mellanox ConnectX-6 HDR100 IB/100GbE VPI 1-port x16 PCIe 3.0 HCA
• Mellanox ConnectX-6 HDR100 IB/100GbE VPI 2-port x16 PCIe 3.0 HCA
• Mellanox ConnectX-6 Dx 100GbE QSFP56 2-port PCIe Ethernet Adapter
Slot 2 > Slot 3 A COM port upgrade kit needs to be installed in slot 2 or 3 as a normal PCIe adapter.
In this case, a riser and bracket are needed.
Slot 1 > Slot 2 > Slot 3 Other PCIe adapters not mentioned above
Notes: For Mellanox ConnectX-6 HDR IB/200GbE Single Port x16 PCIe Adapter, refer
to the following slot priority depending on the quantity of adapters to be installed:
• Two adapters: slot 1, slot 3 or slot 2, slot 3
• Three adapters: slot 1, slot 2, slot 3
Technical rules for GPU adapters
Understanding the technical rules helps you choose the correct GPUs and install them in the supported slots
based on what is configured for your server.
The following are rules for installing GPUs for your server:
Chapter 4. Hardware replacement procedures 89
