Lenze 9325 - Page 415

Configuration
7-294

SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C0866
1
2
3
4
5
6
7
8
9
10
11
DIS: IN1.W1
DIS: IN1.W2
DIS: IN1.W3
DIS: IN2.W1
DIS: IN2.W2
DIS: IN2.W3
DIS: IN2.W4
DIS: IN3.W1
DIS: IN3.W2
DIS: IN3.W3
DIS: IN3.W4
-31-,
-36-,
-51-
-32768.00 {0.01%} 32767.00 Display parameter
DIS: CAN-IN1.W1 (analog)
C0867
1
2
3
4
5
DIS: IN1.D1
DIS: IN2.D1
DIS: IN3.D1
DIS: IN2.D2
DIS: IN3.D2
0
0
0
0
0
Display parameter
DIS: CAN-IN1.D1 (phase)
CAN-OUT
C0151 DIS: FDO (DW) Output signals configured with C0116 Hexadecimal signal assignment of the free digital out-
puts.
l Binary interpretation indicates the bit states
C0353
1
2
3
CAN addr sel1
CAN addr sel2
CAN addr sel3
0
0
0
0{1}1Source for CAN bus IN/OUT addresses
0 C350
1 C354
C0354
2
4
6
CAN OUT1 addr2
CAN OUT2 addr2
CAN OUT3 addr2
129
258
386
1 {1} 513 CAN-Bus OUT node addresses 2
C0355
2
4
6
CAN-OUT1 Id
CAN-OUT2 Id
CAN-OUT3 Id
0 {1} 2047 CAN bus identifier
C0356
2
3
CAN-OUT2 T
CAN-OUT3 T
0
0
0 {1 ms} 65000 CAN bus time settings
[C0860]
1
2
3
4
5
6
7
8
9
10
11
CFG: OUT1.W1
CFG: OUT1.W2
CFG: OUT1.W3
CFG: OUT2.W1
CFG: OUT2.W2
CFG: OUT2.W3
CFG: OUT2.W4
CFG: OUT3.W1
CFG: OUT3.W2
CFG: OUT3.W3
CFG: OUT3.W4
5001
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
@ Selection list 1
[C0861]
1
2
3
CFG: OUT1.D1
CFG: OUT2.D1
CFG: OUT3.D1
1000 @ Selection list 3
