4Technical data
4.1 General data and operating conditions
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4 Technical data
4.1 General data and operating conditions
Range Values
Order designation EMF2180IB
Communication media (system) CAN (ISO 11898)
Ethernet (100 Base TX, IEEE802.3u)
Number of nodes at the CAN bus Max. 100
Baud rate • For communication via CAN
• 20 kbps
• 50 kbps
• 125 kbps
• 250 kbps
• 500 kbps
• 1000 kbps
• For communication via Ethernet
• 10 Mbps
• 100 Mbps
Voltage supply (external) via
separate power supply unit
18 ... 30 V DC, max. 100 mA (in compliance with IEC/EN 61131-2)
Conformity and Approbation
CE See hardware manual of the used inverter.
UL See hardware manual of the used inverter.
EAC TP TC 020/2011
(TR ZU 020/2011)
Electromagnetic compatibility of
technical means
Eurasian Conformity
TR CU: Technical Regulation of
Customs Union
TP TC 004/2011
(TR ZU 004/2011)
On safety of low voltage equipment
Operating conditions Values Deviations from standard
Climatic conditions
Storage 1 K3 to IEC/EN 60721-3-1 - 10 °C ... + 60 °C
Transport 2 K3 to IEC/EN 60721-3-2 - 10 °C ... + 70 °C
Operation 3 K3 to IEC/EN 60721-3-3 - 0 °C ... + 60 °C
Enclosure of the plugged
communication module
IP20
Degree of pollution 2 to IEC/EN 61800-5-1
