Lenze · EMF2180IB communication module (EthernetCAN) · Communication Manual · DMS 5.1 EN · 09/2016 · TD17 43
6 Commissioning
6.3 Before initial switch-on
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.3 Before initial switch-on
Automatic address allocation and detection of the baud rate
The EMF2180IB communication module is provided with the following functions:
• Automatic address allocation
• Automatic detection of the baud rate
These functions are used to prevent failures due to an incorrectly set node address and baud rate.
 Stop!
Before switching on the mains voltage, check ...
• the entire wiring for completeness, short circuit and earth fault:
• whether the bus system is terminated by means of a bus terminating resistor at the
first and last physical bus station.
Connecting the CAN bus
( 20)
 Note!
In the Lenze standard setting, these functions are not activated.
For this, observe the information relating to codes ...
• C0350
(CAN node address)
• C0351
(CAN baud rate)
