1.3 Terminology used
Term Meaning
Code Parameter which serves to parameterise and monitor the drive. In normal usage,
the term is usually referred to as "index".
Subcode If a code contains several parameters they are stored in so-called "subcodes".
In the documentation, the slash "/" is used as a separator between the code and
the subcode (e.g. "C00118/3").
In everyday language, the term is also referred to as "subindex".
Use DHCP The "Dynamic Host Configuration Protocol" (DHCP) is a communication protocol
providing for the assignment of the network configuration to cients by a server.
Engineering PC The Engineering PC and the Engineering tools installed serve to configure and
parameterise the system.
The Engineering PC communicates with the controller via Ethernet.
Engineering tools Lenze software solutions for the configuration and commissioning of Lenze
devices.
The EMF2180IB communication module is configured via the "System bus
configurator", which is part of the following Engineering tools:
• »EASY Starter«
• »Application Loader«
• »Engineer«
• »Drive Server«, from version 1.1 onwards
• »Drive PLC Developer Studio« (DDS), from version 2.2 onwards
• »Global Drive Control« (GDC), from version 4.7 onwards
• »Global Drive Loader« (GDL), from version 2.2 onwards
Commissioning
( 31)
Inverter Generic term for Lenze frequency inverter, servo inverter
FW Firmware
HW Hardware
SW Software
