9 Parameter reference
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C0150
C0200
C0202
Parameter | Name:
C0150 | Status word
Data type: UNSIGNED_16
Index: 24425 = 0x5F69
The binary interpretation of the displayed decimal value reflects the bit statuses of the status word:
• Bit 0: Ready for operation
• Bit 1: Dial-up connection is available
•Bit 2: Internal error
Value is bit-coded:
Bit 0 Ready for operation
Bit 1 Reserved
... ...
Bit 15 Reserved
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C0200 | Software ID
Data type: VISIBLE_STRING
Index: 24375 = 0x5F37
During initialisation, the manufacturer's product code is used to determine which device is connected as node.
The display for the EMF2180IB communication module is "33S2180F_10000".
 Read access  Write access  CINH  PLC-STOP  No transfer
Parameter | Name:
C0202 | Software ID (octet)
Data type: INTEGER_32
Index: 24373 = 0x5F35
In subcodes 1 ... 4, the corresponding octet of the manufacturer's product code is shown.
Display range (min. value | unit | max. value)
-2147483647 2147483647
Subcodes Info
C0202/1 1st octet
C0202/2 2nd octet
C0202/3 3rd octet
C0202/4 4th octet
 Read access  Write access  CINH  PLC-STOP  No transfer
