9 Parameter reference
62 Lenze · EMF2180IB communication module (EthernetCAN) · Communication Manual · DMS 5.1 EN · 09/2016 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C1220
C1224
Parameter | Name:
C1220 | CAN device monitoring
Data type: UNSIGNED_8
Index: 23355 = 0x5B3B
This code serves to ...
• activate the CAN device monitoring function (subcode 0);
• detect interrupted CAN communication for each node and record it in a bit mask (subcodes 1 ... 4) when the CAN
device monitoring function is activated.
Recording of interrupted nodes
Subcodes 1 ... 4 contain a bit mask in which each node (a maximum of 127) with interrupted bus communication or
with an inexistent physical presence is recorded with the value "1".
The status bit immediately adopts the value "0" when communication of the node has been re-established.
For testing purposes, the bit mask can be written to by the user. The values written are accepted at the end of the
CAN device monitoring cycle time in each case (C1217
).
In the »Engineer«, a change-over to the hexadecimal representation is recommended.
Setting range (min. value | unit | max. value)
0 60000
Subcodes Lenze setting Info
C1211/0 0 0: device monitoring not activated
1: device monitoring activated
(Activation can also be carried out via C1219
or the
gateway configuration web page.)
C1211/1 0 Bits: 31 (MSB) ... 0 (LSB)
C1211/2 0 Bits: 63 (MSB) ... 32 (LSB)
C1211/3 0 Bits: 95 (MSB) ... 64 (LSB)
C1211/4 0 Bits: 127 (MSB) ... 96 (LSB)
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C1224 | Gateway address
Data type: UNSIGNED_32
Index: 23351 = 0x5B37
If the communication module is in another subnetwork than the Engineering PC, the IP address of the
corresponding router must be entered into this code
The data are only accepted when the mains has been switched the next time.
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C1224/1 0 Gateway Address 1
C1224/2 0 Gateway Address 2
C1224/3 0 Gateway Address 3
C1224/4 0 Gateway Address 4
 Read access  Write access  CINH  PLC STOP  No transfer
