2/4×counter
4
The modular system
4.21
L
4.21−5
EDSPM−TXXX−9.0−11/2009
Type 2/4×counter
Voltage supply DC 5 V / 80 mA (via backplane bus)
Connectable cable cross−section £ 2.5 mm
2
(³ AWG 14)
Counters
Number 2 × 32−bit counter or 4 × 16−bit counter
Operating modes 38 modes
Counting frequency 1 MHz
Inputs / outputs
External voltage supply DC 24 V (DC 18 ... 28.8 V)
Input signal level LOW: DC −30 ... +5 V
HIGH: DC +13 ... +36 V
Max. output current per output 0.5A
Communication
Input data 10 bytes
Output data 10 bytes
Parameter data 2 bytes
Dimensions
Width 25.4 mm
Height 76.0 mm
Depth 76.0 mm
Weight 100 g
Order number EPM−T410
Technical data
