Lenze EPM-T1 Series - Compact system Mounting

The compact system
6
Mechanical installation
6.2
L
6.2−1
EDSPM−TXXX−9.0−11/2009
6.2 The compact system
Mounting dimensions and other dimensions
34 mm
101 mm
48 mm
34 mm
27 mm
35 mm
76 mm
EPM-T830
34 mm
152 mm
76 mm
69 mm
34 mm
48 mm
EPM-T833
01
01
34 mm
101 mm
76 mm
69 mm
34 mm
48 mm
EPM-T831
01
34 mm
152 mm
76 mm
69 mm
34 mm
48 mm
EPM-T832
01
30 mm
7.5/15 mm
epm−t054
Fig. 6.2−1 Module dimensions of the compact system
