Project planning
Important notes
10
Networking via PROFIBUS−DP
10.4
10.4.1
L
10.4−1
EDSPM−TXXX−9.0−11/2009
10.4 Project planning
10.4.1 Important notes
The I/O system IP20 is configured via the master. The following work steps must
be carried out:
l Install the GSE file (device description) on the master
l Address nodes
l Set the baud rate
l Parameterise slaves
10.4.2 GSE file for PROFIBUS connection
Before the I/O system IP20 can be configured, the device description (GSE file)
has to be installed on the master.
Note that the GSE file has to match the PROFIBUS Gateway (slave) and the
communication protocol used.
Slave Communication protocol GSE file
PROFIBUS Gateway
PROFIBUS−DP−V0 LE000A68.gse
PROFIBUS−DP−V1 LENZ0A68.gse
PROFIBUS GatewayECO
PROFIBUS−DP−V0 LE000A69.gse
PROFIBUS−DP−V1 LENZ0A69.gse
1. Download the correct GSE file from the Internet.
– You can find the GSE files on the Internet under the section "Services &
Downloads" at http://www.Lenze.com.
2. Install the GSE file on the master.
– For notes on the installation, refer to the documentation on the master and
the documentation on the configuration tool.
10.4.3 Setting of the station address
Every node at the PROFIBUS is identified by an address.
l Each address may only be assigned once in a bus system
l Addresses between 1 ... 125 can be assigned.
l At the PROFIBUS Gateway (slave), the address with the front DIP switch is
set.
l At the master, the address is set during the configuration.
10.4.4 Setting of the baud rate
The baud rate is set in the configuration tool.
l The baud rate must correspond to the length of the bus cable.
