8.5 Setting of baud rate and node address (node ID)
Baud rate
For establishing communication, all devices must use the same baud rate for the
data transfer.
l The baud rate can be set via the coding switch at the module.
Node address
Each node of the network must be assigned to a node address, also called Node ID
within a range of 1 ... 63 for clear identification.
l A node address in a network may be used only once.
l The node address must be set with the coding switch at the module.
0
1
++
––
epm−t024
Fig. 8.5−1 Coding switch at CAN gateway
–
Decrease numerical value
+
Increase numerical value
System bus (CAN)
Baud rate
Coding switch value [kbit/s]
90 1000
91 500
92 250
93 125
94 100
95 50
96 20
97 10
98 800
Bold print = Lenze setting
1. Switch off the voltage supply of the module.
2. Use the coding switch to set the required baud rate.
– Select "9x" (x = value for the required baud rate)
3. Switch on the voltage supply of the module.
– The LEDs ER, RD and BA are blinking with a frequency of 1 Hz.
4. LEDs ER and BA go off after 5 seconds, and the set baud rate is stored.
Baud rate setting
