Lenze EPM-T1 Series - Status of the Analog Inputs; Status of the Analog Outputs

Diagnostics
Status of the analog inputs
9
Network via CANopen
9.10
9.10.6
L
9.10−5
EDSPM−TXXX−9.0−11/2009
9.10.6 Status of the analog inputs
Via the index I6401
h
the status of the analog inputs can be displayed.
Index Name Possible settings Important
Lenze Selection
I6401
h
Analog input −32768 {1} 32767
Display only
Analog input status
Index is only available in the modular
system
 9.10−5
1 Channel 1
2 Channel 2
... ...
36 Channel 36
9.10.7 Status of the analog outputs
Via the index I6411
h
the status of the analog outputs can be displayed:
Index Name Possible settings Important
Lenze Selection
I6411
h
*
Analog output −32768 {1} 32767
· Analog output status
· The outputs can be set manually
(forcing):
– Depends on CAN status and I2360
h
· Index is only available in the modular
system
 9.10−5
1 Channel 1
2 Channel 2
... ...
36 Channel 36
