Lenze EPM-T1 Series - Modular system Mounting

The modular system
6
Mechanical installation
6.1
L
6.1−1
EDSPM−TXXX−9.0−11/2009
6.1 The modular system
Mounting dimensions and other dimensions
01
80 mm
60 mm
110 mm
27 mm
7.5/15 mm
35 mm
80 mm
90 mm
74 mm
74 mm
76 mm 76 mm
25.4 mm
25.4 mm
epm−t053
Fig. 6.1−1 Module dimensions of the modular system
