13.1.10 Signal functions of 4xanalog input /output
) Note!
l Short−circuit unused inputs (connect positive and negative
terminals) or deactivate them by assigning the function number
FF
h
.
l In the event of an overflow or underflow, wrong values are
output. Strong signal jumps with sign reversal may occur.
I/O system IP20 multiplies measured values with decimal positions and without
normalisation by a factor and transfers them as integers to the bus. To output the
decimal positions, divide the measured values by the same factor.
Example:
Measuring task: Temperature measurement with signal function 01
h
. Measured value = 80.5 °C.
1. I/O system IP20 converts the measured value into an integer:
80.5 [°C] × 10 = 805
2. Reconvert the measured value to output it with decimal positions:
805[°C]
10
 + 80.5°C
Paramete
r bytes
2/3
Signal function Signal range Format
1)
Tolerance
2)
00
h
24 Parameter data in module are not overwritten
3Bh Voltage
measurement
±10 V
−10.00
−16384
{0.01V}
{1
dec
}
+10.00
+16384
S5
Two’s
complement
±0.2 %
Min. Limit
values
Max.
−12.50 V
−20480
dec
+12.50 V
+20480
dec
2Bh Voltage
measurement
±10 V
−10.00
−16384
{0.01V}
{1
dec
}
+10.00
+16384
S5
Sum and sign
±0.2 %
Min. Limit
values
Max.
−12.50 V
−20480
dec
+12.50 V
+20480
dec
72
h
Voltage
measurement
1 ... 5 V
+1.00
0
{0.01V}
{1
dec
}
+5.00
+16384
S5
Sum and sign
±0.6 %
Min. Limit
values
Max.
0.00
−4096
dec
+6.00 V
+20480
dec
75
h
Voltage
measurement
0 ... 10 V
0.00
0
{0.01V}
{1
dec
}
+10.00
+16384
S5
Two’s
complement
±0.4 %
Min. Limit
values
Max.
0.00
0
+12.50 V
+20480
dec
Input functions
