Lenze EPM-T1 Series - Status of the Digital Outputs

Diagnostics
Status of the digital outputs
8
Networking via system bus (CAN)
8.10
8.10.5
L
8.10−4
EDSPM−TXXX−9.0−11/2009
Index
Name Possible settings Important
Lenze Selection
I6000
h
Digital input 0 {1} 255
Display only
Digital input status
 8.10−3
1 Module 1
2 Module 2
... ...
64 Module 64
8.10.5 Status of the digital outputs
Via the index I6200
h
the status of the digital outputs can be displayed:
Index Name Possible settings Important
Lenze Selection
I6200
h
*
Digital output 0 {1} 255
· Digital output status
· The outputs can be set manually
(forcing):
– Depends on CAN status and I2360
h
 8.10−4
1 Module 1
2 Module 2
... ...
64 Module 64
