EDSPM−TXXX
.Aùð
Ä.Aùðä
System Manual
I/O−System IP20
EPM−T1XX, EPM−T2XX, EPM−T3XX, EPM−T4XX, EPM−T9XX
Modular system
Compact system

Table of Contents

Questions and Answers

  • A
    Anna LewisAug 14, 2025
    What to do if there is no HIGH level output at the Lenze EPM-T1 digital output?
    • C
      Christopher RobinsonAug 14, 2025
      If the Lenze I/O Systems digital output doesn't show a HIGH level, there might be a few reasons: * There could be a short circuit due to incorrect wiring: In this case, you should check the wiring. * The connected load might be defective: In this case, check the load. * The digital output may be overloaded because the load's current consumption is too high: Try selecting a load with lower current consumption. If you're using an 8×digital output 1A module, consider replacing it with an 8×digital output 2A module if possible.
  • D
    Debra RobinsonAug 17, 2025
    Why is there no data transfer in my Lenze EPM-T1 I/O Systems?
    • F
      fitzgeraldsusanAug 17, 2025
      If the Lenze I/O Systems is not transferring data, it might be due to the module not receiving the necessary 24 V DC supply voltage. Ensure the module is properly supplied with 24 V DC.
  • M
    Matthew SkinnerAug 21, 2025
    What to do if the Lenze EPM-T1 relay contact does not open?
    • G
      garrett02Aug 21, 2025
      If the Lenze I/O Systems relay contact isn't opening, it's possible that excessive load has caused the relay contact to fuse. You should replace the module and reduce the load on the relay contact.
  • M
    Michele HamiltonAug 25, 2025
    What to do if the signal at the Lenze EPM-T1 I/O Systems analog input is not transmitted?
    • C
      carolyn17Aug 25, 2025
      If the Lenze I/O Systems are not transmitting the signal at the analog input, consider the following possibilities: 1. There might be an open circuit within the measuring range of 4 ... 20 mA, so check the wiring. 2. There may be no sensor connected, so connect the sensor. If an input is not in use, short-circuit the plus and minus terminals. 3. The input current might be greater than 40 mA, so reduce the input current.
  • M
    Michael RandallAug 27, 2025
    Why is no process data transmitted in my Lenze EPM-T1?
    • M
      Matthew StoneAug 27, 2025
      If the Lenze I/O Systems are not transmitting process data, it could be because the system bus is in the "Pre?Operational" state. To resolve this, transmit telegram 00 01 00 from the master to change the system bus to the "Operational" state.
  • L
    lauren00Aug 30, 2025
    How to fix incorrect data transmission to the backplane bus in Lenze EPM-T1 I/O Systems?
    • H
      Haley SimmonsAug 31, 2025
      If the Lenze I/O Systems module isn't making proper contact with the backplane bus, it can cause incorrect data transmission. To solve this, place the module on the DIN rail and turn it downward until you hear it engage. Then, restart the module by disconnecting and reconnecting the supply voltage.
  • J
    Janet WallaceSep 3, 2025
    What to do if Lenze EPM-T1 parameter changes were not saved after supply voltage disconnection?
    • H
      Holly HamiltonSep 3, 2025
      If changes to parameters on your Lenze I/O Systems aren't being saved after you disconnect the supply voltage, it's likely because the parameter changes were not saved. To ensure changes are saved, use index I2003h to save all settings.
  • T
    Tiffany AustinSep 6, 2025
    Why HIGH signal at a digital input is not transmitted/indicated in Lenze EPM-T1?
    • J
      Jennifer ParkerSep 6, 2025
      If the HIGH signal at a digital input on your Lenze I/O Systems is not being transmitted or indicated, it could be due to the high signal lacking a reference potential (GND) via pin 10. To fix this, establish a reference potential.
  • T
    Tami MorrisonSep 9, 2025
    Why value 0 is not transmitted to the master via the digital input IN1 / IN4 after a reset in Lenze EPM-T1?
    • G
      gregoryparkSep 9, 2025
      If, after a reset, the value 0 is not transmitted to the master via the digital input IN1 / IN4 when networking takes place via system bus (CAN) or CANopen with your Lenze I/O Systems, it is because the process data transfer to the master (PDO?Tx) is event?controlled. Setting cyclic process data change (I1800h ... I1809h) should resolve the issue.

Summary

Preface

The I;O system IP20

Overview of the I/O system IP20, detailing its modular and compact system concepts and their applications.

How to use this System Manual

Explains how to navigate and utilize the system manual, including target audience, content structure, and information retrieval.

Legal regulations

Details labelling requirements, manufacturer information, CE conformity, and application directives for the I/O system.

Safety instructions

Definition of notes used

Explains the structure and meaning of safety notes, including pictographs, signal words, and their consequences.

Technical data

General data;operating conditions

Covers conformity, approval, protection types, EMC, ambient, mounting, and station design specifications.

The modular system

Gateways (CAN, PROFIBUS)

Covers CAN Gateway, CAN GatewayECO, PROFIBUS Gateway, and PROFIBUS GatewayECO modules, including features and configuration.

Digital I;O Modules

Describes 8x and 16x digital input, output, and input/output modules, including features and terminal assignments.

Analog Modules

Details 4x analog input and output modules with various ranges, including signal functions and technical data.

Counter and SSI Modules

Covers 2/4xcounter modules with various modes and the SSI interface module, including parameterization and signal characteristics.

Terminal Module

Explains the terminal module's features, overview, and technical data for wiring.

The compact system

Compact I;O Modules (8 x, 16 x, 32 x)

Details 8x, 16x (single/three-wire), and 32x digital I/O compact modules, including features and configuration.

Mechanical installation

Modular system Mounting

Provides mounting dimensions and details for installing and dismounting modular system components on DIN rails.

Compact system Mounting

Details mounting dimensions and installation/dismounting procedures for compact system modules on DIN rails.

Electrical installation

Wiring according to EMC

Provides guidelines for wiring to ensure electromagnetic compatibility, covering assembly, shielding, and earthing.

System bus wiring (CAN, PROFIBUS)

Covers wiring and communication connections for CAN, CANopen, and PROFIBUS-DP system buses.

Networking via system bus (CAN)

Via system bus (CAN)

Introduces the CAN system bus, detailing its structure, identifiers, and saving changes.

Network management (NMT)

Explains network management functions, communication phases, telegram structure, and state transitions for the CAN network.

Transmitting process data

Covers process data telegrams, PDO identifiers, parameter assignment, transmission modes, and process images.

Transmitting parameter data

Details parameter data, telegram structure, writing and reading parameters, and setting baud rate/node address.

Node Guarding and Heartbeat

Explains Node Guarding and Heartbeat protocols for monitoring slave connections and their configuration.

Diagnostics

Details diagnostics for system bus status, module identifiers, digital and analog input/output status, and error reporting.

Networking via CANopen

About CANopen

Introduces the CANopen protocol, its structure, identifiers, and saving changes.

Network management (NMT)

Explains network management functions, communication phases, telegram structure, and state transitions for CANopen.

Transmitting process data

Covers process data telegrams, PDO identifiers, parameter assignment, transmission modes, and process images for CANopen.

Transmitting parameter data

Details parameter data, telegram structure, writing and reading parameters, and setting baud rate/node address for CANopen.

Node Guarding and Heartbeat

Explains Node Guarding and Heartbeat protocols for monitoring slave connections and their configuration for CANopen.

Diagnostics

Details diagnostics for system bus status, module identifiers, digital and analog input/output status, and error reporting for CANopen.

Networking via PROFIBUS-DP

Via Profibus-DP

Introduces PROFIBUS-DP, covering its power sections V0 and V1, and diagnostic functions.

System configuration

Details PROFIBUS-DP system configuration types, including mono-master and multi-master systems.

Communication

Explains bus access, cyclic data transfer, acyclic data transfer, and communication medium for PROFIBUS-DP.

Project planning

Covers essential steps for project planning, including GSE files, station address, and baud rate settings.

Transmitting parameter data

Details parameter data transmission for PROFIBUS-DP-V0 and V1, addressing with slot and index, and consistent parameter data.

Diagnostics

Explains diagnostic functions, diagnostic data structure, code-related, module, and channel-related diagnostics.

Commissioning

System bus (CAN); CANopen

Covers pre-switching checks and commissioning examples for system bus (CAN) and CANopen.

PROFIBUS-DP

Details pre-switching checks and initialization procedures for PROFIBUS-DP.

Parameter setting via system bus (CAN); CANopen

Important notes

Provides crucial information regarding the use of I/O system IP20 with CoDeSys-PLC and CANopen mode.

Parameterising digital modules

Explains parameter data for digital modules, covering polarity and configuration.

Parameterising analog modules

Details parameter data, signal functions, and diagnostic data for analog modules.

Parameterising 2;4 xcounter module

Covers parameter data, input/output data, counter modes, and signal characteristics for 2/4xcounter modules.

Parameterising SSI interface

Explains parameter data, input/output data assignment, and process data mapping for the SSI interface.

Parameterising 1 xcounter;16 xdigital input module

Details parameter data, input/output data, encoder modes, and signal characteristics for counter/digital input modules.

Transmitting parameter data

Explains how to transmit parameter data, including saving changes and loading default settings.

Loading default setting

Describes the procedure for resetting all parameter changes to the default factory settings.

Parameter setting via PROFIBUS-DP

Parameterising analog modules

Details parameter data, signal functions, and conversion for analog modules used with PROFIBUS-DP.

Parameterising 2;4 xcounter module

Covers parameter data, input/output data, counter modes, and signal characteristics for 2/4xcounter modules with PROFIBUS-DP.

Parameterising SSI interface

Explains parameter data, input/output data, and process data mapping for SSI interface modules with PROFIBUS-DP.

Parameterising 1 xcounter;16 xdigital input module

Details parameter data, input/output data, encoder modes, and signal characteristics for counter/digital input modules with PROFIBUS-DP.

Troubleshooting and fault elimination

Fault messages

Lists common faults for modules like CAN gateway, digital I/O, analog modules, and counters, with their display, cause, and remedy.

Appendix

Index table

Provides an alphabetical index of terms, abbreviations, and references to relevant pages within the manual.

Glossary

Defines key terminology and abbreviations used throughout the system manual for clarity.

Lenze EPM-T1 Series Specifications

General IconGeneral
CategoryI/O Systems
SeriesEPM-T1
Number of Digital Inputs8
Number of Digital Outputs8
Output Current per Channel0.5 A
Protection ClassIP20
Operating Temperature Range0°C to +55°C
