Lenze EPM-T1 Series - Index table

Index table
15
Appendix
15.1
L
15.1−1
EDSPM−TXXX−9.0−11/2009
15.1 Index table
l The indices are numbered in ascending order for reference purposes.
l How to read the index table:
Column Abbreviation Meaning
Index
Ixxxx
h
Index Ixxxx
h
1 Subindex 1 of Ixxxx
h
2 Subindex 2 of Ixxxx
h
Ixxxx
h
¿
After entry, the index parameter value is stored in the EEPROM
Ixxxx
h
*
Index parameter value is stored in the EEPROM with I2003
h
= 1
Name Index name
Lenze Lenze setting, setting on delivery
Selection 1 {%}
99
min. value {unit} max. value
Important
– Brief, important explanations
 Page x Reference to detailed explanations
Index Name Possible settings Important
Lenze Selection
I1000
h
Device type Display only
Type
I1001
h
Error register
Display only
 8.10−2
Bit 0 Generic An unspecified error has occurred
(flag set on each error message)
Bit 1 Reserved
Bit 2 Reserved
Bit 3 Reserved
Bit 4 Comm. Communication error (Overrun CAN)
Bit 5 Reserved
Bit 6 Reserved
Bit 7 ManSpec. Manufacturer−specific error Shown in detail in I1003
h
I1003
h
Display only
History buffer
1 Actual errors
I1004
h
Number of
supported PDOs
Display only
1 Number of
synchronous PDOs
supported
2 Number of
synchronus PDOs
supported
I1005
h
*
Sync COB−ID 128 128 {1} 2047
I1006
h
*
Sync interval (ms) 0 0 {1 ms} 4294967295 · I/O system IP20 acts as sync consumer:
– Set bit 30 = 0 under I1005
h
– After the time set under I1006
h
,
I/O system IP20 switches to the
communication status set under
I1029
h
– A reset will be carried out with the
next sync telegram
– With I1006
h
= 0, the monitoring is
deactivated
· I/O system IP20 acts as sync producer:
– Set bit 30 = 1 under I1005
h
(Lenze
setting)
– I/O system IP20 transmits the sync
telegram after the time set under
I1006
h
