Lenze EPM-T1 Series User Manual

How to use this System Manual
Products to which the System Manual applies
1
Preface
1.2
1.2.2
L
1.2−2
EDSPM−TXXX−9.0−11/2009
1.2.2 Products to which the System Manual applies
This documentation is valid for the I/O system IP20 as of the nameplate data:
   Nameplate
EPM−T XXX 1A 13
Type
epm−t008
L
XX XxDC24V
.0
.1
.2
.3
.4
.5
.6
.7
1
2
3
4
5
6
7
8
9
L
10
EPM – TXXX 1A.10
EPM – TXXX 1A
PW
ER
RD
BA
ADR.
0
1
+
–
DC
24V
X1

110 CAN gateway
111 CAN GatewayECO
120 PROFIBUS Gateway
121 PROFIBUS GatewayECO
210 8×digital input
211 16×digital input
220 8×digital output 1A
221 8×digital output 2A
222 4×relay
223 16×digital output 1A
224 8×digital output 0.5A
225 16×digital output 0.5A
230 8×digital input / output
310 4×analog input
311 4×analog input ±10V
312 4×analog input ±20mA
320 4×analog output
321 4×analog output ±10V
322 4×analog output 0...20mA
330 4×analog input / output
410 2/4×counter
411 SSI interface
430 1×counter/16×digital input
830 8×dig. I/O compact
831 16×dig. I/O compact (single−wire
conductor)
832 32×dig. I/O compact
833 16×dig. I/O compact (three−wire
conductor)
940 Terminal module
Hardware version
Software version
Types EPM−T1XX, EPM−T3XX, EPM−T4XX and EPM−T8XX only
