Terminal module
4
The modular system
4.24
L
4.24−2
EDSPM−TXXX−9.0−11/2009
Type
Terminal module
Terminals
Terminal strips 2 spring−mounted clamps, not plug−in
Terminals per strip 11
Max. current capacity per terminal strip 10A
Connectable cable cross−section £ 2.5 mm
2
(³ AWG 14)
Dimensions
Width 25.4 mm
Height 76.0 mm
Depth 76.0 mm
Weight 50 g
Order designation EPM−T940
Technical data
