Transmitting process data
Indices for setting the process data transmission
8
Networking via system bus (CAN)
8.3
8.3.9
L
8.3−11
EDSPM−TXXX−9.0−11/2009
8.3.9 Indices for setting the process data transmission
Process data objects for input data
Index
Name Possible settings Important
Lenze Selection
I1400
h
¿
Index is available in the modular and
compact system
 8.3−3
1 COB−ID used by
RxPDO 1
768 385 {1} 2047 Defining the individual identifiers for
process data object 1
2 Transmisson type 255
0 {1} 255 Defining the transmission mode
0 ... 240 Process data update on sync telegram
transmission
The input data are accepted on sync
telegram transmission.
241
... 254
Reserved
255 Process data update on occurrence of an event Every received value is accepted
... ...
I1409
h
¿
Index is only available in the modular
system
 8.3−3
1 COB−ID used by
RxPDO 10
1665 385 {1} 2047 Defining the individual identifiers for
process data object 10
2 Transmisson type 255
0 {1} 255 Defining the transmission mode
0 ... 240 Process data update on sync telegram
transmission
The input data are accepted on sync
telegram transmission.
241
... 254
Reserved
255 Process data update on occurrence of an event Every received value is accepted
