Transmitting parameter data
Addressing with slot and index
10
Networking via PROFIBUS−DP
10.5
10.5.3
L
10.5−6
EDSPM−TXXX−9.0−11/2009
l
In the case of PROFIBUS Gateway, the 32 electronic modules can be
accessed via slot numbers 1 ... 32.
l In the case of GatewayECO, the 8 electronic modules can be accessed via
slot numbers 1 ... 8.
Slot number Index Access Description
1 ... 32 00
h
R Read out diagnostic data record 0
W Write parameters to the module
01
h
R The corresponding diagnostic data record of the electronic module can be
read out via the index.
· Example:
– Index 01
h
: read out diagnostic data record 1
– Index 02
h
: read out diagnostic data record 2
F1
h
R Read out the module parameters
F2
h
R Read out the process image of the module
R = read
W = write
Data of electronic modules
